OPTi 604/6848 - Step 3: Connecting Console

a. Connect the wires as shown in the diagram,then insert the wires into the handles holes;
b. Fix each side of the Console to the two Console Mast (2 & 3) with 4 x 55mm Allen Bolt (58) , 4 x 8mm
Spring Washers (60) and 4 x
Ф
8 x R20mm Arc Washer (62).
9
Console
3
Step 3
Assembly Instructions
60
58
62
2
58
60
62
1
