Bluetooth Application Quick Setup - Guide
2.3 Supported defaults
The following default settings are supported.
(The labels below can be read without reading any SET/END labels)
Bluetooth HID *
(default)
* If you only have an Opticon Universal menu book available which doesn't list 'C02' or 'C05' as supported defaults,
it's possible to use RS232 ('U2') or Bluetooth ('SO') instead of 'C05'.
All listed defaults are also available at http://opticonfigure.opticon.com/ (Defaults)
In case it’s required to (also) be able to transmit any scanned barcodes using USB-VCP (COM port) or USB-HID
(keyboard), then it’s possible to do this by reading one of the labels below.
USB-VCP
(+ Bluetooth VCP)
USB-HID
(+ Bluetooth HID)
Notes:
• When using USB-HID it’s not directly possible to load software using Appload. To be able to load software,
switch back to Bluetooth-VCP or USB-VCP default.
• Transmission by USB only works while not being connected to Bluetooth
• From application version RFL3791F it is also possible to configure the Bluetooth name of the device.
Set Bluetooth Local Name
OPN2006_yyyy where yyyy is the
last four digits of the Bluetooth
address ( default )
Set Bluetooth Local Name
OPN2006_xxxxxx where xxxxxx is
the serial number.
