Assembly and maintenance instruction recirculating ball screw
5. Dezember 2007 Page 35Recirculating ball screw assembly and maintenance instruction ; Version 2.0
© 2007
GB
£ Re-assemble the slide of the Z-axis.
£ Shift the V-ledge on the slide of the
Z-axis. Clamp or adjust it using the
lock screw.
Fig.1-61: Assembly Z-axis
Slide Z-axis
Z-axis
V-ledge
Lock screw
