Assembly and maintenance instruction recirculating ball
OPTIMUM
MASCHINEN - GERMANY
5. Dezember 2007Page 36 Recirculating ball screw assembly and maintenance instruction ; Version 2.0
© 2007
GB
£ Insert the spindle into the Z-axis.
£ Mount the support (part 1) on the
support (part 2).
£ Fix it using the lock screw. Make
sure that the support is correctly
positioned.
Fig.1-62: Assembly Z-axis
Spindle Z-axis
Z-axis
Support
Lock screw
