Assembly and maintenance instruction recirculating ball screw
5. Dezember 2007 Page 9Recirculating ball screw assembly and maintenance instruction ; Version 2.0
© 2007
GB
£ Drag the feather key from the
spindle.
Fig.1-14: Disassemble feather key
£ Remove pillow block, if necessary
strike with a plastic tip hammer.
Fig.1-15: Disassemble pillow block
£ Loosen the V-ledge at the locking
screw.
Fig.1-16: Loosen V-ledge
Feather key
Pillow block
Locking screw
