Command Description Response Description
IR03000 Response "IR03000" after PC received a inviald or failed command
IR04901? Request IP Configuration IR25901n
n=AAAAAAAANNNNNNNNGGGGGGGGDDDDDDDDPC
A: IP Address from MSB to LSB(ex. 10.0.21.22->0A001516)
N: Subnet Mask
G: Gateway
D: DNS
P: DHCP Mode(0/1: Off/ON)
C: RJ-45 Connector State(0/1: Disconnect/Connect)
IR0A902nnnnnnn Send Email Alert
Byte1: Error State(0/1/2/3/4/5: Normal/Thermal Switch Error/Fan
Lock/Over Temperature/Lamp Hours Running Out/Lamp Fail)
Byte2~5: Lamp Hour 4 bytes Hex. string
B
y
te6~7: Tem
p
erature 2 b
y
tes Hex. strin
g
IR03902
IR0500010 Response "IR0500010" SMTP not ready
IR03903 Set Network Module to Default IR03903
IR22904n Setting IP Configuration
n=AAAAAAAANNNNNNNNGGGGGGGGDDDDDDDD
A: IP Address from MSB to LSB(ex. 10.0.21.22->0A001516)
N: Subnet Mask
G: Gateway
D: DNS
IR03904
IR04905n Setting DHCP Mode, n=1/0 : DHCP ON/OFF IR03905
Additional Resources
Byte1: Power State 0/1/2: Power OFF/Power ON/Cooling IR04090n
Byte2: Error State
0/1/2/3/4/5: Normal/Thermal Switch Error/Fan Lock/ Over
Temperature/Lamp Hours Running Out/Lamp Fail
Byte3~6: Lamp Hour String 4 digitals, (MSB~LSB)
Byte7: Current Source 0~9: D-sub Analog RGB~Composite Video
Byte8: Display Format 0/1/2/3: 4:3/16:9/Window/Native
Byte9: Display Mode 0/1/2/3/4: PC/Movie/Game/sRGB/User
Byte10: Digital Source 0/1: OFF/ON
Byte11~12: Volume 00~14 (Hex Value) IR05070nn
Byte13~14: Treble 00~0F (Hex Value) IR05071nn
Byte15~16: Bass 00~0F (Hex Value) IR05072nn
Byte17~18: Brightness 00~64 (Hex Value) IR05080nn
Byte19~20: Contrast 00~64 (Hex Value) IR05081nn
Byte21~22: Color 00~64 (Hex Value) IR05082nn
Byte23~24: Tint 00~64 (Hex Value) IR05083nn
Byte25: AV Mute 0/1: AV Mute OFF/AV Mute
Byte26: Freeze 0/1: Unfreeze/Freeze
Byte27: Mute 0/1: OFF/ON
Byte28: Stereo/Mono 0/1: Mono/Stereo IR04073n
Byte29: Lamp Litted 0/1: Fail/Success
Byte1: Screen 0/1/2: Single/PIP Window/Split Screen
Byte2: PIP Size
0/1/2: Small/Normal/Large
Byte3: PIP Location
0/1/2/3/4: Left-Top/Right-Top/Center/Left-Bottom/Right-Bottom
Byte4: Projection Mode 0/1/2/3/4: Ceiling/Rear Ceiling/Front/Rear Front
Byte5: Auto Shutdown 0/1/2/3/4/5/6: OFF/1 min/3 min/4 min/10 min/20 min/30 min
Byte6: Brite Mode 0/1: OFF/ON
Byte7: Image Shift 0/1/2: OFF/Position 1/Position 2
Byte8~11: V. Image Shift FF7D~FFFF-0000-0001~0083(Hex Value) User input value is from -131 to +131
Byte12~13: Zoom Value F6~FF-00-01~0A(Hex Value) User input value is from -10 to +10
Byte14: White Peaking 0~A (Hex Value) IR04061n
Byte15: Blanking Color 0/1: Blue/Black
Byte16: Lamp Reminding 0/1: OFF/ON
Byte17~18: Language 00~0D IR05057nn
Byte19~20: Sharpness 00~06 (Hex Value) IR05084nn
Byte21~22: Frequency 00~64 (Hex Value) IR05085nn
Byte23~24: Tracking 00~64 (Hex Value) IR05086nn
Byte25~26: V. Position 00~64 (Hex Value) IR05088nn
Byte27~28: H. Position 00~64 (Hex Value) IR05087nn
Byte29~30: Color Temperature 00/01/02: Low/Medium/High IR04032n
Byte31~32: V. Keystone D8 ~ FF-00 ~ 28 (Hex Value) User input value is from -40 to +40
Byte33~34: H. Keystone D8 ~ FF-00 ~ 28 (Hex Value) User input value is from -40 to +40
Byte35: Degamma 0~3 (Hex Value)
Byte36: Zoom 0/1/2: OFF/Zoom 1/Zoom 2
(IR04099?)Projector status 2, bytes description
Network Module Response to Projector Projector Send to Network Module (IRxx9xx…)
(IR04098?)Projector status bytes description
EP910 RS232
