5.2 The backside of mainboard
Connector Description
No 1 Connect to DMD Board
No 2 Fan2
No 3 Color Wheel Sensor
No 4 Connect to Power Board
No 5 Ballast control
No 05
No 02
No 01
No 04
No 03
