Optoma HD66 - Page 50

---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

~XX71 1 7E 30 30 37 31 20 31 0D Projection Front-Desktop

~XX71 2 7E 30 30 37 31 20 32 0D Rear-Desktop

~XX71 3 7E 30 30 37 31 20 33 0D Front-Ceiling

~XX71 4 7E 30 30 37 31 20 34 0D Rear-Ceiling

---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

~XX72 1 7E 30 30 37 32 20 31 0D Menu Location Top Left

~XX72 2 7E 30 30 37 32 20 32 0D Top Right

~XX72 3 7E 30 30 37 32 20 33 0D Centre

~XX72 4 7E 30 30 37 32 20 34 0D Bottom Left

~XX72 5 7E 30 30 37 32 20 35 0D Bottom Right

---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

~XX73 n 7E 30 30 37 33 20 a 0D Signal Frequency n = -5 (a=2D 35) ~ 5 (a=35) By signal

~XX74 n 7E 30 30 37 34 20 a 0D Phase n = 0 (a=30) ~ 31 (a=33 31) By signal

~XX75 n 7E 30 30 37 35 20 a 0D H. Position n = -5 (a=2D 35) ~ 5 (a=35) By timing

~XX76 n 7E 30 30 37 36 20 a 0D V. Position n = -5 (a=2D 35) ~ 5 (a=35) By timing

---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

~XX77 n 7E 30 30 37 37 20 aabbcc 0D Security Security Timer Month/Day/Hour n = mm/dd/hh

mm = 00 (aa=30 30) ~ 12 (aa=31 32)

dd = 00 (bb=30 30) ~ 30 (bb=33 30)

hh = 00 (cc=30 30) ~ 24 (cc=32 34)

~XX78 1 7E 30 30 37 38 20 31 0D Security On

~XX78 0 7E 30 30 37 38 20 32 0D Off (0/2 for backward compatible)

---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

~XX79 n 7E 30 30 37 39 20 a 0D Projector ID n = 00 (a=30 30) ~ 99 (a=39 39)

~XX80 1 7E 30 30 38 30 20 31 0D Mute On

~XX80 0 7E 30 30 38 30 20 30 0D Off (0/2 for backward compatible)

~XX81 n 7E 30 30 38 31 20 a 0D Volume n = 0 (a=30) ~ 10 (a=31 30)

---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

~XX82 1 7E 30 30 38 32 20 31 0D Logo Optoma

~XX82 2 7E 30 30 38 32 20 32 0D User

~XX83 1 7E 30 30 38 33 20 31 0D Logo Capture

---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

~XX100 1 7E 30 30 31 30 30 20 31 0D Source Lock On

~XX100 0 7E 30 30 31 30 30 20 30 0D Off (0/2 for backward compatible)

~XX101 1 7E 30 30 31 30 31 20 31 0D High Altitude On

~XX101 0 7E 30 30 31 30 31 20 30 0D Off (0/2 for backward compatible)

~XX102 1 7E 30 30 31 30 32 20 31 0D Information Hide On

~XX102 0 7E 30 30 31 30 32 20 30 0D Off (0/2 for backward compatible)

~XX103 1 7E 30 30 31 30 33 20 31 0D Keypad Lock On

~XX103 0 7E 30 30 31 30 33 20 30 0D Off (0/2 for backward compatible)

---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

~XX104 1 7E 30 30 31 30 34 20 31 0D Background Color Blue

~XX104 2 7E 30 30 31 30 34 20 32 0D Black

~XX104 3 7E 30 30 31 30 34 20 33 0D Red

~XX104 4 7E 30 30 31 30 34 20 34 0D Green

~XX104 5 7E 30 30 31 30 34 20 35 0D White

---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

~XX105 1 7E 30 30 31 30 35 20 31 0D Advanced Direct Power On On

~XX105 0 7E 30 30 31 30 35 20 30 0D Off (0/2 for backward compatible)

~XX106 n 7E 30 30 31 30 36 20 a 0D Auto Power Off (min) n = 0 (a=30) ~ 180 (a=31 38 30)

~XX107 n 7E 30 30 31 30 37 20 a 0D Sleep Timer (min) n = 0 (a=30) ~ 999 (a=39 39 39)

~XX114 1 7E 30 30 31 31 34 20 31 0D Power Mode(Standby) Eco.(<=1W)

~XX114 0 7E 30 30 31 31 34 20 30 0D Active (0/2 for backward compatible)

---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

~XX109 1 7E 30 30 31 30 39 20 31 0D Lamp Reminder On

~XX109 0 7E 30 30 31 30 39 20 30 0D Off (0/2 for backward compatible)

~XX110 1 7E 30 30 31 31 30 20 31 0D Brightness Mode Bright

~XX110 0 7E 30 30 31 31 30 20 30 0D STD (0/2 for backward compatible)

~XX111 1 7E 30 30 31 31 31 20 31 0D Lamp Reset Yes

~XX111 0 7E 30 30 31 31 31 20 30 0D No (0/2 for backward compatible)

---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

~XX112 1 7E 30 30 31 31 32 20 31 0D Reset Yes

---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

~XX99 1 7E 30 30 39 39 20 31 0D RS232 Alert Reset Reset System Alert

---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

SEND to emulate Remote

---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

~XX140 1 7E 30 30 31 34 30 20 31 0D Power

~XX140 10 7E 30 30 31 34 30 20 31 30 0D Up/Page +

~XX140 11 7E 30 30 31 34 30 20 31 31 0D Left/Source

~XX140 12 7E 30 30 31 34 30 20 31 32 0D Enter (for projection MENU)

~XX140 13 7E 30 30 31 34 30 20 31 33 0D Right/Re-SYNC

~XX140 14 7E 30 30 31 34 30 20 31 34 0D Down/Page -

~XX140 15 7E 30 30 31 34 30 20 31 35 0D Keystone +

~XX140 16 7E 30 30 31 34 30 20 31 36 0D Keystone -

~XX140 17 7E 30 30 31 34 30 20 31 37 0D Volume -

~XX140 18 7E 30 30 31 34 30 20 31 38 0D Volume +

~XX140 19 7E 30 30 31 34 30 20 31 39 0D Brightness (1)

~XX140 20 7E 30 30 31 34 30 20 32 30 0D Menu (2)

~XX140 21 7E 30 30 31 34 30 20 32 31 0D Zoom (3)

~XX140 22 7E 30 30 31 34 30 20 32 32 0D HDMI (4)

~XX140 23 7E 30 30 31 34 30 20 32 33 0D Freeze (5)

~XX140 24 7E 30 30 31 34 30 20 32 34 0D AV Mute (6)

~XX140 25 7E 30 30 31 34 30 20 32 35 0D S-Video (7)

~XX140 26 7E 30 30 31 34 30 20 32 36 0D VGA (8)

~XX140 27 7E 30 30 31 34 30 20 32 37 0D Video (9)

---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

SEND from projector automatically

---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

232 ASCII Code HEX Code Function Projector Return Description

---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

when Standby/Warming/Cooling/Out of Range/Lamp fail/ INFOn n: 0/1/2/3/4/6/7/8 = Standby/Warming/Cooling/Out of Range/Lamp fail/

Fan Lock/Over Temperature/Lamp Hours Running Out Fan Lock/Over Temperature/Lamp Hours Running Out

---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

READ from projector

---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

232 ASCII Code HEX Code Function Projector Return Description

---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

~XX121 1 7E 30 30 31 32 31 20 31 0D Input Source Commands OKn n : 0/1/2/3/4

None/HDMI/VGA/S-Video/Video

~XX122 1 7E 30 30 31 32 32 20 31 0D Sofware Version OKdddd dddd: FW version

~XX123 1 7E 30 30 31 32 33 20 31 0D Display Mode OKn n : 0/1/2/3/4/5/6/7/8 = None/Presentation/Bright/Movie/sRGB/User1/

User2/Blackboard/Classroom

~XX124 1 7E 30 30 31 32 34 20 31 0D Power State OKn n : 0/1 = Off/On

~XX125 1 7E 30 30 31 32 35 20 31 0D Brightness OKn

~XX126 1 7E 30 30 31 32 36 20 31 0D Contrast OKn

~XX127 1 7E 30 30 31 32 37 20 31 0D Aspect Ratio OKn n=0/1/2/3/4/5 for 4:3/16:10/LBX/Native/AUTO

~XX128 1 7E 30 30 31 32 38 20 31 0D Color Temperature OKn n : 0/1/2 = Warm/Medium/Cold

~XX129 1 7E 30 30 31 32 39 20 31 0D Projection Mode OKn n : 0/1/2/3 = Front-Desktop/ Rear-Desktop/ Front-Ceiling/ Rear-Ceiling

~XX150 1 7E 30 30 31 35 30 20 31 0D Information OKabbbbccdddde
