Optoma TW762 - Compatibility Modes: Computer

56
English
Appendices
For widescreen
resolution
(WXGA), the
compatibility
support is
dependent on
Notebook/PC
models.
120Hz input
signals may be
dependent on
graphics cards
support.
Please note that
using resolutions
other than native
1024 x 768 (XGA
model), 1280
x 800 (WXGA
model) may result
in some loss of
image clarity.
Compatibility Modes
Computer Compatibility

Mode Resolution
Anglog/Digital
V-Sync (Hz) H-Sync (KHz)
VGA 640 × 350 70 31.50
VGA 640 × 350 85 37.90
VGA 640 × 400 85 37.90
VGA 640 × 480 60 31.50
VGA 640 × 480 67 -
VGA 640 × 480 72 37.90
VGA 640 × 480 75 37.50
VGA 720 × 400 70 31.50
VGA 720 × 400 85 37.90
SVGA 800 × 600 56 35.20
SVGA 800 × 600 60 37.90
SVGA 800 × 600 72 48.10
SVGA 800 × 600 75 46.90
SVGA 800 × 600 120 -
832 × 624 75 -
XGA 1024 × 768 60 48.40
XGA 1024 × 768 70 56.50
XGA 1024 × 768 75 60.00
XGA 1024 × 768 120 -
1152 × 870 75 -
HD 1280 x 720 60 45.00
HD 1280 x 720 120 -
WXGA-800 1280 x 800 60 -
SXGA 1280 x 1024 60 64.00
1366 x 768 60 -
1440 x 900 60 55.935
SXGA+ 1400 x 1050 60 -
UXGA 1600 × 1200 60 75.00
1680 x 1050 60 -
HDTV 1920 x 1080 30 33.80
