EN-50
Ceiling mount installation
1. To prevent damage to your projector, please use the Optoma ceiling
mount.
2. If you wish to use a third party ceiling mount kit, please ensure the screws
used to attach a mount to the projector meet the following specifications:
Screw type: M4*3
Maximum screw length: 8mm
Minimum screw length: 6mm
Note
Please note that damage resulting from incorrect installation will void the warranty.
Warning
1.If you buy a ceiling mount from another company, please be sure to
use the correct screw size. Screw length will vary depending on the
thickness of the mounting plate.
2.Be sure to keep at least 10 cm gap between the ceiling and the bottom
of the projector.
3.Avoid installing the projector near a heat source.
Lens
55.0
110.0
103.5 108.1
114.4
82.3
27.6
Unit: mm
73.1
68.5
