15
FOR TESTABLE MODELS ONLY: Check installation
again as done in Step 23 to ensure poppet actuates and
resets properly. See page 17 for full testing details. Ap-
ply pipe dope to the socket adaptor threads. Pipe dope
should be a non-hardening gasoline resistant pipe
thread seal compound. Install socket adaptor and
torque to 3.5 ft-lbs (42 in-lbs) minimum to 5.0 ft-lbs (60
in-lbs) maximum. After installing socket adaptor where
required, pressure test testable overll valve per CARB
TP201.1D to ensure valve is vapor tight.
Figure 24
Orient socket
adaptor be-
tween jack
screw bolts
Figure 24A
To Next Page
