Oracle Sun Fire X2270 M2 Getting Started Guide

▼ Install Optional Components
Before mounting the server in a rack, install any optional components that you ordered for your server (for
example, DIMMs and HBA cards).
♦ See the Sun Fire X2270 M2 Server Service Manual for the instructions on installing components.
▼ Mount the System in a Rack
♦ To safely and properly mount the server in a rack, see the instructions included with the rail kit, the
service label on the server, or the Sun Fire X2270 M2 Server Installation Guide.
Front and Back Panel Connections and Features
FIGURE 1 Back Panel Connections
FIGURE 2 Front Panel Features
1 AC Power connector 5 USB 2.0 ports (2)
2 Serial Management (SER MGT) RS-232 RJ-45 serial
port
6 Network Management (NET MGT) Ethernet port
(available only in systems that contain a service
processor module)
3 Gigabit Ethernet port (NET-0) 7 HD15 video connector (available only in systems that
contain a service processor module)
4 Gigabit Ethernet port (NET-1)
1 Green Power/OK LED 2 Power button 3
Serial Number
2
6
3
5
4
1
7
1
2
3

Oracle Sun Fire X2270 M2 Specifications

General

Brand	Oracle
Model	Sun Fire X2270 M2
Category	Server
Language	English
