Orange Pi PC User Manual Shenzhen Xunlong Software CO., Limited
www.orangepi.org www.xunlong.tv
Hardware Specification
CPU H3 Quad-core Cortex-A7 H.265/HEVC 4K
GPU Mali400MP2 GPU @600MHz, Supports OpenGL ES 2.0
Memory (SDRAM) 1GB DDR3 (share with GPU)
Onboard Storage TF card (Max. 64GB) / MMC card slot
Onboard Network 10/100M Ethernet RJ45
Video Input
A CSI input connector Camera：
Supports 8-bit YUV422 CMOS sensor interface
Supports CCIR656 protocol for NTSC and PAL
Supports SM pixel camera sensor
Supports video capture solution up to 1080p@30fps
Audio Input MIC
Video Output
Supports HDMI output with HDCP
Supports HDMI CEC
Supports HDMI 30 function
Integrates CVBS
Supports simultaneous output of HDMI and CVBS
Audio Output HDMI and 3.5mm Jack
Power Source DC input, USB OTG input don’t supply power
USB 2.0 Port Three USB 2.0 HOST, one USB 2.0 OTG
Button Power Button(SW4)
Low-level peripherals 40 Pins Header, compatible with Raspberry Pi B+
