USING YOUR AMPLIFIER
1. Input Jack: This also acts as the ON/OFF switch. A guitar lead must be connected here for the unit
to function. This is to conserve battery life when not in use.
2. Overdrive: Depress this switch to activate the overdrive function.
3. Tone: Adjusts the brightness of the tone.
4. Volume: This control adjusts the distortion gain. Turning it clockwise increases the distortion
intensity whilst increasing output levels.
5. Power: This powers the unit on/off when there is a lead connected to the input jack.
6. Power Indicator: This LED indicates if the unit is switched on.
