Orange_Pi-2(H3)
CON3-P01 VCC-3V3
CON3-P02 VCC-5V
CON3-P03 TWI0-SDA PA12
CON3-P04 VCC-5V
CON3-P05 TWI0-SCK PA11
CON3-P06 GND
CON3-P07 PWM1 PA6
CON3-P08 UART3_TX PA13
CON3-P09 GND
CON3-P10 UART3_RX PA14
CON3-P11 UART2_RX PA1
CON3-P12 PD14 PD14
CON3-P13 UART2_TX PA2
CON3-P14 GND
CON3-P15 UART2_CTS PA3
CON3-P16 PC4 PC4
CON3-P17 VCC-3V3
CON3-P18 CAN_RX PC7
CON3-P19 SPI0_MOSI PC0
CON3-P20 GND
CON3-P21 SPI0_MISO PC1
CON3-P22 UART2_RTS PA2
CON3-P23 SPI0_CLK PC2
CON3-P24 SPI0_CS0 PC3
CON3-P25 GND
CON3-P26 PA21 PA21
CON3-P27 TWI1-SDA PA19
CON3-P28 TWI1-SCK PA18
CON3-P29 PA7 PA7
CON3-P30 GND
CON3-P31 PA8 PA8
CON3-P32 UART1_RTS PG8
CON3-P33 PA9 PA9
CON3-P34 GND
CON3-P35 PA10 PA10
CON3-P36 UART1_CTS PG9
CON3-P37 PA20 PA20
CON3-P38 UART1_TX PG6
CON3-P39 GND
CON3-P40 UART1_RX PG7
