Orava EC-322 - Page 15

15
EN
1 left cooking plate (large)
2 right cooker plate (small)
3 temperature setting thermostat for the oven
4 light for the thermostat
5 left large plate output power setting thermostat
6 indicator lamp for cooking plates
7 Right-hand power setting thermostat (small)
8 Grill switch and heating elements switch
9 Grill
10 drip tray/baking sheet
11 grill bar handle
12 barbecue rack
13 handle for drip tray/baking sheet
14 feet of the oven
15 glass oven door
16 door handle
14
15
16
1
2
3
4
5
6
7
8
9
10
11
12
13
3
4
5
6
7
8
