Orban 424A - Page 51

Modules
A1
Module Assy, Timing 30590-000-xx*
CRB
*Add suffix printed on part
A2
Module Assy, DSC 30585-000-xx* ORB Add suffix
printed on
part
Resistors
R5 Pot, Single,
5K, (5020)
20728-000
CRB
20%
CW Log
R14
Pot, Single, 50K,
(5050)
20727-000
CRB
Linear
R55 Pot,
Single, 10K, (5020R)
20723-000
CRB
20% CCW Log
R64 Pot,
Single,
10K, (5050)
20744-000
ORB Linear
R68
Pot, Single,
100K, (5020)
20726-000
CRB 20% CW Log
R72
Pot, Single, 50K, (5050)
20727-000 ORB Linear
R79 Pot, Dual, 50K/50K, (5020R)
20745-000
CRB 20% OCW Log
R92
Pot, Single,
10K,
(5050)
20720-000
ORB
Linear
FOOTNOTES:
(1)
See
last page for abbreviations
(2)
No
Alternate Vendors known
at
publication
(3)
Actual part is
specially
selected frcm
part
listed, consult Factory
Realignment
may
be
required if replaced, see
Circuit
Description
and/or Alignment
Instructions
SPECIFICATIONS
AND
SOURCES FOR
REPLACEMENT PARTS
GATED COMP/UM
MODEL
bZlMblkh
PCB Main
Assembly
-
Modules,
Resistors
Swi
tches
,
Trans i
s
tors
