Orbea MX JUNIOR 16 2021 - 06 Technical Specifications; Model-Specific Technical Data; Usage Guidelines and Fitment

TECHNICAL MANUAL16 | ORBEA ORBEA | 17
EN
BLUE PAPER MX JUNIOR · 2021
06 TECHNICAL SPECIFICATIONS
MX JUNIOR
MX12 MX16 MX20 MX24
FRAME MATERIAL MAGNESIUM ALUMINUM 6061 ALUMINUM 6061 ALUMINUM 6061
FORK MATERIAL
(rigir forks)
MAGNESIUM HI-TEN STEEL
ALUMINUM 6061
(Team) HI-TEN STEEL
(Dirt/Park)
ALUMINUM 6061
(Team) HI-TEN STEEL
(Dirt/Park)
BRAKE TYPE - V-BRAKE
V-BRAKE
Compatible with
IS 160mm disc brake
V-BRAKE
Compatible with
IS 160mm disc brake
FORK TRAVEL
(models with
suspension forks)
-
- 80mm 80mm
FORK MAXIMUM
LENGTH
(Axle-to-crown)
220mm 254mm 347mm 418mm
HEADSET
1-1/8"
Semi integrated
1-1/8"
Semi integrated
1-1/8"
Semi integrated
1-1/8"
Semi integrated
MAXIMUM NUMBER
OF HEADSET SPACERS
0 0 0 0
BOTTOM BRACKET - BSA 68mm BSA 68mm BSA 68mm
BB AXLE LENGTH
SQUARE TAPERED
- 110.5mm 110.5mm 115mm
SEATPOST DIAMETER 27.2mm 27.2mm 27.2mm 27.2mm
SEATPOST CLAMP
DIAMETER
31.8mm 31.8mm 31.8mm 31.8mm
WHEEL SIZE 12" 16" 20" 24"
MAXIMUM TYRE
WIDTH
2.2" 2.0" 2.2" 2.2"
REAR HUB LENGTH
(O.L.D)
100mm 113mm 135mm 135mm
FRONT HUB LENGTH
(O.L.D)
100mm 100mm 100mm 100mm
REAR AXLE STAN-
DARD
QR
(with safety bolts)
QR
(with safety bolts)
QR QR
MX12 MX16 MX20 MX24
FRONT AXLE
STANDARD
QR
(with safety bolts)
QR
(with safety bolts)
QR QR
BRAKE CABLE
ROUTING
-
EXTERNAL
(Full housing)
EXTERNAL
(Full housing)
EXTERNAL
(Full housing)
REAR DERAILLEUR
CABLE ROUTING
- -
INTERNAL IN DT
EXTERNAL ON C/STAY
(Full housing)
INTERNAL IN DT
EXTERNAL ON C/STAY
(Full housing)
BOTTLE HOLDER NO
1
Lower downtube
mounting
Orbea Junior 350ml
1 1
COMPATIBLE WITH
FULL MUDGUARDS
NO NO YES YES
FRONT DERAILLEUR NO
NO
(Single speed)
NO
Only 1X
NO
Only 1X
DRIVETRAIN
COMPATIBILITY
- SINGLE SPEED
UP TO 10S
MTB & LEISURE
UP TO 10S
MTB & LEISURE
CHAINGUIDE
COMPATIBLE
-
NO
Chain cover
YES YES
KICKSTAND
COMPATIBLE
NO YES YES YES
RACK COMPATIBLE NO NO NO NO
AGE RANGE
(Years old)
2-4 3-6 4-8 6-10
HEIGHT RANGE
(cm)
80-105 95-120 110-135 125-150
WEIGHT LIMIT
(kg)
20 30 40 50
INTENTED USE
RECREATIONAL
SUPERVISED
(No trafc)
RECREATIONAL
SUPERVISED
(No trafc)
RECREATIONAL
SUPERVISED
(No trafc)
RECREATIONAL
SUPERVISED
(No trafc)
