Replacing the Battery
To remove and replace the battery:
Insert your finger in the battery removal groove at the top edge of the battery cover,
then lift and remove the battery cover. Set the cover aside.
Insert your finger into the battery removal divot
and lift the battery out of the battery compartment.
Align the gold contacts on the new battery with the gold contacts
on the Mobile Hotspot and gently slide the battery into place.
1
2
3
