Orbis DATA MICRO 2+ - Technical Specifications and Dimensions; Technical Features; Dimensions and Protection

T
ECHINCAL FEATURES
Voltage rating As indicated on the unit
Tolerance ± 10%
Breaking power µ 2x16 (10) A / 250 V~
M
aximum recommended loads (N/O):
Incandescent lamps: 3000 W
F
luorescent lamps 1200 VA
Low voltage halogen lamps 2000 VA
Halogens (230 V) 3000 W
Low-consumption lamps 600 VA
Downlights 400 VA
Leds 600 VA
Self-consumption 7.3 VA (1.2 W)
Contact AgSnO
2
switched
Operational accuracy ± 1 s/day at 23 ºC
Variation of accuracy with temp. ± 0.15 s / ºC / 24 h
Running reserve 4 years (without mains supply connection)
T
ype of action DATA MICRO+: 1B, 1S, 1T, 1U
DATA MICRO 2+: 1S, 1T, 1U
Software class and structure Class A
Memory slots 32
Nº of channels DATA MICRO +: 1
DATA MICRO 2+: 2
Types of operation ON; OFF
PULSE: from 1 to 59 seconds
Operating precision ± 1 s
Operating temperature -10 ºC to +45 ºC
Transport and storage Temp -20 ºC to +60 ºC
Contamination situation 2
Protection degree IP 20 as per EN 60529
Protection class II in proper assembly
Ball test temperature + 75 ºC for 21.2.5
Keypad accesses cover Lockable
Connection By means of needle post for maximum
cable section of 4 mm²
Casing dimensions 2 DIN modules (35 mm)
DIMENSIONS
05/06.2013 A016.17.52821
ORBIS TECNOLOGIA ELECTRICA, S.A.
Lérida, 61 E-28020 MADRID
Teléfono: +34 91 5672277; Fax: +34 91 5714006
E-mail: info@ orbis.es
http://www.orbis.es
6
0
65
45
88
3
5
