User Manual - Thermo X
• Operating conditions:
- temperature 0°C ÷ +50°C
- relative humidity 20% ÷ 90%, non-condensing
• Storage temperature: -10°C ÷ +65°C
• Protection rating: IPXXD
• Insulation class: II
INSTALLATION AND ASSEMBLY
It is advisable to install the programmable thermostat in a zone in which the
temperature is the closest to the room average value.
Do not install it too near doors, windows, sources of heat, direct sunlight
or in places in which there is too much or too little air fl ow.
Installing the programmable thermostat about 150 cm from the fl oor is
recommended.
Mounting can be on a wall or on a 503 box.
PLACEMENT REMOVAL
