21
C1 DC motor
1
C17 1
C2 Motor bracket
1
C19 Controller 1
C3 Incline motor
1
C20 Upper console wire 1
C4 Running board
1
C21 Lower console wire 1
C5 Cylinder
1
C22 Left quick button 1
C6 Motor belt
1
C23 Right quick button 1
C7 Rear roller
1
C24 Handle pulse 2
C8 Front roller
1
C25 Speed sensor 1
C9 Running belt
1
C26 Safety key 1
C10 Power switch
1
C27 Safety key sensor 1
C11 Power line
1
C28 Magnetic ring 2
C12 Outlet
1
C29 Single line 1
C13 Single ground line
1
C30 Single line 1
C14 Single line
1
1
C15 Single line 1
C32 Chest belt
1
C16 Overload protector 1
C33 MP3 Line
Single line
D Hardware parts
No. Description
QTY
No. Description
QTY
D1 Allen wrench S6mm 1 D18 Cross head bolt M6X25 2
D2 Round hex bolt M10X45 3 D19 Cross head bolt M6X40 2
D3 Round hex bolt M10X15 4 D20 Cross head bolt M6X65 4
D4 Round hex bolt M10X65 2 D21
Cross self-tapping bolt
ST4.2X65
4
D5 Round hex bolt M10X55 6 D22
Cross self-tapping bolt
ST2.9X19
4
D6 Round hex bolt M8X50 4 D23
Cross self-tapping bolt
ST4.2X16
31
D7 Round hex bolt M8X30 1 D24
Cross self-tapping bolt
ST4.2X19
10
D8 Round hex bolt M8X40 2 D25
Cross self-tapping bolt
ST3.5X16
2
D9 Round hex bolt M8X45 1 D26 Nylon nut M10 3
C Electric and drive parts
No.
Description
QTY
No.
Description
QTY
