Orbit ST37A.1 User Manual

23
C3 Rear roller
1
C17 Lower wire
1
C4 Front roller
1
C19 MP3 cable
1
C5 Running deck
1
C20 Magnetic ring
1
C6 Cylinder
1
C23 Overload protector
1
C7 Drive belt
1
C27 Single cord (black)
1
C8 Power switch
1
C28 Speed sensor
1
C9 Controller
1
C29
Han pulse sensor 2
C10 Quick buttons on left handrail
1
C31 Short single cord (red)
2
C11 Quick buttons on right handrail
1
C32 Short single cord (black)
1
C12 Incline motor
1
C33 Grounding cable
1
C13 Safety key
1
C34 3-pin outlet
1
C14 Single cord (red)
1
C37
Chest belt 1
D. Hardware
No. Description Qty No. Description Qty
D1 Screw driver 13-15-17
1
D26 Arc washer
6
D2 Allen wrench T6
1
D31 Hex head round bolt M8X20
4
D4 Round head hex bolt M10X65
2
D33 Hex head round bolt M8X55
1
D5 Round head hex bolt M8X100
1
D34 Hex head round bolt M8X60
2
D6 Round head hex bolt M8X50
2
D36 Cross head bolt M6X25
4
D8 Round head hex bolt M10X15
4
D39 Cross head bolt M6X40
4
D10 Round head hex bolt M10X45
2
D41
Cross head self-tapping bolt
4.2X70
4
D11 Round head hex bolt
M10X50
1
D44
Cross head bolt M5X12,
washer
1
D12 Round head hex bolt M10X55
6
D45
Cross head bolt M5X15,
washer
5
D14 Round head hex bolt M8X30
1
D46
Cross head bolt M5X20,
washer
2
D15 Round head hex bolt M8X40
2
D48
Cross head self-tapping bolt
ST4.2X19, washer
12
D16 Round head hex bolt M8X45
1
D50
Cross head self-tapping bolt
ST4.2X25, washer
2
D18 Nylon nut M10
3
D51 Cross head bolt M5X8
4
D20 Nylon nut M8
8
D52
Cross head self-tapping bolt
ST4.2X16
34
D21 Flat washer M10
17
D57
Cross head self-tapping bolt
ST4.2X25
4
D23 Flat washer M8
19
D58
Cross head self-tapping bolt
ST3.5X16
4
D24 Spring washer M5
2 D59
Cross head self-tapping bolt
ST2.9X25
4
D25 Spring washer M8
4
D62
Incline rotating tube
2
D28 Hex head round bolt M10X20
2
D69
Round head hex bolt M8X55
2
