Orbit ST37A.1 User Manual

22
A. Welding parts
No. Description Qty No. Description Qty
A1 Main frame 1
A5 Incline bracket
1
A2 Base frame 1
A7 Deck supporting tube
1
A3L Left upright 1
A11 Motor frame
1
A3R Right upright 1
A13 Running belt fixing bracket
2
A4 Handrail bracket 1
B. Plastic parts
No. Description Qty No. Description Qty
B1 Console set
1
B20 Round plug
1
B1-1 Overlay
1
B21 Squared plug
4
B1-2 Membrane key
1
B22 Left motor side cover
1
B1-3 Console
1
B23 Right motor side cover
1
B1-5 iPad holder
1
B26 Deck cushion
2
B2 Console panel
1
B27 Cushion set
4
B3 Protecting foam
2
B30L Left anti-slippery pad 1
B4 Handrail plug
2
B30R Right anti-slippery pad 1
B5
Console back cover 1
1
B31 Rubber pad
2
B6 Transporting wheel cover
2 B34 EVA pad (for iPad holder) 1
B8 Flat feet pad
4
B43 PVC cushion
2
B9 U-shape feet pad
2
B44 EVA pad 1
B11L Left side cover
1 B45 Console back cover 2 1
B11R Right side cover
1
B49 Bottle holder 2
B13 Motor upper cover
1 B58 Handrail cover 1 2
B15 Side rail
2
B59 Handrail cover 2 2
B16L Left end cap
1 B65L Left console side cover 1
B16R Right end cap
1 B65R Right console side cover 1
B17 Adjusting wheel
4
B81 USB rubber cover 1
C. Electric parts
No. Description Qty No. Description Qty
C1
DC motor
1
C15 Power cable
1
C2 Running belt
1
C16 Upper wire
1
Parts list

Orbit ST37A.1 Specifications

General

Brand	Orbit
Model	ST37A.1
Category	Treadmill
Language	English
