Orbit X304 - Assembly Step 1; Assembly Step 1: Explosion Drawing

Assembly step（1）explosion drawing
6
8
2
6
4
1
5
3
7
9
10
11
9
9
9
10
9
10
9
9
9
22
22
Install ALL bolts/ nuts before ghtening.
Do not over ghten.
No. Descripon Note Qty.
1 connecon tube 1
2 upright frame le 1
3 upright frame right 1
4 bending tube le 1
5 bending tube right 1
6 upper connecon tube 1
7 upper bending tube 1
8 upper bending tube le 1
9 hexagon bolt M10*75 16
10 lock nut M10 16
11 washer Φ10 32
22 foot tube cover 2
