Orbit X304 - Assembly Step 1: Assembly Instructions

Assembly step（1）drawing
7
Assembly step（1）assembly instrucon
1 Fix bending tube le-4 fastening on upright frame le-2 using M10x75 hexagon bolt-9, Φ10
washer-11 and M10 lock nut-10
2 Fix bending tube right-5 fastening on upright frame right-3 using M10x75 hexagon bolt-9, Φ
10 washer-11 and M10 lock nut-10
3 Fix connecon tube-1 fastening with bending tube le-4, bending tube right-5 using M10x75
hexagon bolt-9, Φ10 washer-11 and M10 lock nut-10
4 Fix upper connec
on tube-6 fastening on upright frame using M10x75 hexagon bolt-9, Φ10
washer-11 and M10 lock nut-10
5 Fix upper bending tube le-8 fastening on upright frame le-2 using M10x75 hexagon bolt-9,
Φ10 washer-11 and M10 lock nut-10
6 Fix upper bending tube right-7 fastening on upright frame right-3 using M10x75 hexagon bolt-
9, Φ10 washer-11 and M10 lock nut-10
7 Tighten all bolts and nuts before connuing.
