Orca 300 CL - Technical Information; Technical Specifications; Spare Elements Identification

14
1.4 Technical informations
a. Technical specifications
Rated output voltage of adapter: 30V
Rated input voltage of adapter: 100 V – 240 V
Rated output current of adapter : 2.0 A
Input power of adapter : 50 Hz – 60 Hz
Working Cycle : 2 h
Moving speed: about 10 m / min
Cleaning surface : 120 ㎡
Charging temperature : 0℃ / 40℃
Filter capacity : 16 m³/h
Operating temperature: 10℃ / 40℃
Filter capacity: 180 μm
IP Indice d’étanchéité : IPX8
battery lithium 25.9V 7.8AH.
b. Spare elements
Filter
Roller block
Main driving pulley
Belt 162 XL
Belt T10
Protection part of impeller
Impellller
Upper cover of sealing unit
O ring（∅31.5*3.55）
Battery
LED PCB
Cleaner PCB
Pump motor
Drive motor
O ring（∅20*2.65）
Upper cover of sealing
* Charger
