BATTERY REPLACEMENT
1. As shown in the figure, insert the battery with the anode side (+) toward
the light head.
2. Please do not reverse battery to avoid damage to the flashlight and
battery.
3. Please do not use battery with higher voltage than the flashlight working
voltage.
4. Please do not use battery with damaged surface or deformation to avoid
short circuit, explosion, leakage, etc.
User manual
OPERATION INSTRUCTIONS
PRODUCT INTRODUCTION
ORCATORCH D550 is a small and light weight tail magnetic switch diving
light. It is equipped with a totally sealed magnetic controlled tail switch
which offers high waterproofness and easy operation underwater. Using
the latest USA CREE LED, max 1000 lumens output and near to 6 hours
runtime, this portable diving light offers high and low two modes and one
strobe mode for different diving environment use. Plus robust water
pressure resistant construction, high portability and easy operation, D550
would be qualified for both recreational diving as a primary light and deep
diving as a backup light.
1. ON/OFF: Insert the battery and tighten the light head to turn on the
flashlight at default low mode, press the tail switch to turn it off.
2. Mode Selection: Press the tail switch to switch mode among high, low
and off. Keep pressing the tail switch for about 1 second to get the hidden
strobe mode, and press again to get back to the previous mode.
3. The total runtime will be extended significantly if the light is used
discontinuously.
Reason A: The batteries need to be replaced.
Solution: Replace batteries (Please confirm correct installation of + and -
terminals).
Reason B: The threads, PCB board contact or other contacts are dirty.
Solution: Clean the contact points with an alcohol soaked cotton swab.
If the methods above don't work, please contact the distributors and refer
to the warranty policy.
² Do not drop or place the light on sand in case iron sand stick or go into
switch section or screw thread.
² Tighten all the connections of the light before going underwater.
² Please take out the batteries after each diving.
² Please don't disassemble the sealed head, doing so may cause damage
to the flashlight and will void the warranty.
² We recommend the use of high quality batteries. If the flashlight will not
be used for a long time, remove the batteries to avoid damage from
electrolyte leakage or battery explosion.
² Please replace the O-rings if they are damaged after prolonged use and
regularly lubricate the o-rings so as to not erode the rubber. Doing so will
keep the flashlight properly sealed against water.
² Please clean the contacts of your light from time to time, especially
when the light flickers or doesn't light up. There are probably several
reasons for a flickering or not working light:
USAGE AND MAINTENANCE
² Please keep the flashlight away from high intensity magnetic fields, or the
switch may fail to function.
² Please clean the surface of the light with fresh water and wipe it dry after
use in case of the seawater corrosiveness.
PRODUCT FEATURES
Cree LED, 1000 lumens output
Uses one 18650 battery
Magnetic controlled tail switch offers high waterproofness and easy
operation underwater
Standard included wrist strap fastens the flashlight to the back of your
hand
Water pressure resistant construction ,depth rated to 150 meters
Reverse polarity protection, to protect from improper battery installation
Over-discharge protection function
Aircraft-grade high strength aluminum material
The latest diamond grade hard-anodized seawater-corrosion-resistance
finish
Alloy aluminum reflector with professional optical analysis
Two sides coated toughened glass with high water pressure resistance
under deep water
TECHNICAL PARAMETERS
ANSI/NEMA FL1
Output
Runtime
Intensity
Waterproof
Working voltage
Dimension
Net weight
Accessories
3 – 4.2 V
144mm(Length) x 25mm(Diameter) x 41mm(Head)
200g（excluding battery）
1* 18650 USB Type-C Rechargeable Battery，1*Lanyard
1* USB Type-C Charging Cable， 1*Wrist Strap， 3* Spare O-ring
Beam
Distance
Impact
Resistant
Low
380 Lumens
4h20min
244m (On land)
15000cd
1.5m
under water 150m
High
1000 Lumens
2h
Strobe
1000 Lumens
/
Notice: Stated data has been measured according to the international
flashlight test standards ANSI/NEMA FL1 using one OrcaTorch 18650 Li-ion
batteries (3.7V, 3400mah) under laboratory conditions. The parameters are
approximate and may vary between flashlights, batteries, and environments.
Max 1000 Lumens
We will replace products afflicted with manufacturing defects within 30
days of purchase and repair a light free of charge within 12 months of
purchase if problems develop under normal use; if repair is required after
12 months from the date of purchase, we will charge for parts. The total
repair fee is dictated by the cost of the replaced materials.
PRODUCT WARRANTY
Warning
The flashlight is high intensity lighting device and capable of causing
eye damage, please avoid shining the light directly into the eyes.
Please register your OrcaTorch products through official website
www.orcatorch.com to get extra 1 year warranty.
Tel:+86-755-33560383 Fax:+86-755-29454989
Email: info@orcatorch.com www.orcatorch.com
Address: 4th Floor, Building 6, Huafeng Science and
Technology Park, 535 Fengtang Avenue, Fuyong,
Bao'an District, Shenzhen, China 518103
ORCATORCH TECHNOLOGY LIMITED
www.orcatorch.com
Tai l S witc h
