OREC RM60W
21
TIP :
HST oil replacement
First : at 20 hours
Later : at each 200 hours or 1 year whichever comes first
References: (The color of HST oil)
Color
Smell
Status
To do
Clean and no changing color.
Good
No foreign object
Use as usual
Clean, but there are some black points.
Good
Some foreign object
Use after filtering
Milky white
Good
Some water.
Change the oil
Black
Bad
Oxidated and degrade.
Change the oil
Recommended oil : “VG46” or “SAE10W30“.
Oil quantity : 500 ml.
VG46 oil is used when it is shipped from factory. Refill the same type of oil. Never mix different type of oil.
GREASE LUBRICATION
CAUTION
Refer to position of grease nipple in the figure here below, and grease up at every 30 hours of use. In other part
of machine, lubricate with engine oil(#30). If grease is not properly lubricated, it leads to poor movement of
machine and cause damages. Grease nipple is located in each axle part. Use grease gun to lubricate.
④
⑤ ⑥
⑦ ⑧ ⑨
⑩ ⑪
⑫
⑬
