Increase Quality Through Interaction with the Field
Disassembly
Step 1
Service Screw
Step 2
Park Interlock Switch
Main Power Switch
Cord Winder Actuator
Park Cover & Pedals Removed
Step 3
Motor Speed Control
Slide Panel Removed
Increase Quality Through Interaction with the Field
14
