Oreck DTX1100 - Table of Contents; Troubleshooting DTX1300;1400 Electrical

Increase Quality Through Interaction with the Field
Table of Contents
Tune-up Pages 3-7
Wiring Diagrams
DTX1100/1200 Page 7
DTX1300/1400 Page 8
Troubleshooting DTX1300/1400 Electrical
Circuits Explained
Test Points & Troubleshooting Page 9-13
Disassembly Figures of DTX1300/1400 Pages 13-23
Cord Winder Replacement w/o Disconnecting Everything
Page 24
Cord Winder Disassembly
Pages 25
Tighten the Tension on the Cord Winder
Page 26
Helpful Assembly Hints Page 27
Hose Handle Interior
Page 28
EBK340 Power Nozzle Service Pages 28-34
EBD280/340 Motor Cog Removal
Page 34
DTX1100/1200 Rear Cover Removal
Pages 35-39
