Step 26
N
ote the orientation of the motor
brushes
N
ote the orientation of the motor
leads.
Spacer & Grommets
Step 27
The foam silencer has
cutouts for the motor brush
locations.
Foam Silencer
Step 28
Remove Motor
Step 31
