CS1400 CHAINSAW
Quick Start Instructions
TENSIONING THE SAW CHAIN
STEP 6:
Loosen the side cover release
knob slightly, but do not remove the
side cover.
STEP 7:
Hold up the nose of the guide
bar (A) and turn the chain tensioning
ring clockwise.
STEP 8:
Tighten the chain tensioning
ring until the lowest cutters
underneath the bar solidly contact the
bar (B).
IMPORTANT: The saw chain must be
properly tensioned before using.
ATTENTION! SAFETY NOTICE
Wear Chainsaw Protective Gloves
A
7
ATTENTION! SAFETY NOTICE
Unplug the chainsaw
6
BLACK
B
8
RED
B
STEP 9:
Lightly pull on the chain. The tension is correct when the chain snaps back
after being pulled 3 mm away from the guide bar.
STEP 10:
After a short period of use, allow the chain to cool, unplug the chainsaw
and check the tension again. Watch tension carefully for the rst half-hour of use and
periodically throughout the life of the chain readjusting as required when the chain
and bar are cool to the touch. Never tension chain when it is hot.
Chain will stretch as a result of normal use, however, insucient oil, aggressive use,
or failure to perform recommended maintenance can lead to premature stretching.
CORRECT
WARNING An electric power tool that is plugged in can start accidentally.
Unplug the chainsaw before preparing for use or performing maintenance.
WARNING If the chain is still loose when the saw is at maximum tension, replace
the chain.
IMPORTANT Only tension the saw chain when the chain is cool.
INCORRECT
9
IMPORTANT SAFETY NOTICE
Remember to always use appropiate protective
equipment whenever operating a chainsaw.
(Chain shown here in both photos is conventional chain and not PowerSharp)
CS1400 ASSEMBLY INSTRUCTIONS.06.08.2019.indd 2 06/08/2019 13:25:46
