35
d. Press key so that the buzzer beeps to indicate the new
location of the motor is accepted automatic ally by the
splicer. Th is way the adjustment is done .
e. Press key to return.
T Left Motor
2010
-
02
-
26 9
:
35 24
℃
43
%
RH
X
Y
Figure A-4
Note:
Note:
Note:
Note:
If the left and right motors are close to the V-grooves, the two 16 mm
stripping-length fibers may collide or one of them occupies the whole
screen. In this case , the fibers could be located after the splicer enters
the motor-adjustment status. The motors can be adjusted one after
another.
If the ground ing condition is good and the
RESET
key is pressed before
the instrument is turned off, the position of motors will need no
adjustment for quite a long time.
