OrienTek T40 - Fiber Cleaver Maintenance

48
Cleaving button
Bare fiber clamp
Fiber holder groove
Blade carrier
Figure H- 1
H.3
H.3
H.3
H.3 Maintenance(Refer
Maintenance(Refer
Maintenance(Refer
Maintenance(Refer to
to
to
to Figure
Figure
Figure
Figure H-
H-
H-
H- 2)
2)
2)
2)
Blade fixing screw Blade
Blade height
adjustment screw
Blade height locking screw
Figure H- 2
If cleaving conditions become poor try the following steps.
1. Clean the upper and lower rubber surfaces of the bare fiber
clamp and blade edge using a cotton swab moistened with
