Origen ae S16T - S16 T Overview; Features and Controls Overview

1
5
98
4
6
11
15 16 17 18
24
25
26 26
Power button
Blue LED ring
External TFT on/off (under chassis)
One piece aluminum chassis
7” TFT touch panel
Top panel
TFT menu controls
Optical disk drive (ODD) bezel
Soft-eject access panel
I/O ports/multi-format card reader
ODD eject button
IR receiver window
Door latch
IR receiver PCB
Intake vent
I/O ports/card reader PCB
ODD cage
TFT button PCB
4th HD mount bracket
IR310 IR controller PCB
TFT module
Primary hard drive cage
Side intake vent
92mm low dB fan
Top panel fixing screw
80mm low dB fan
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
S16T overview
These are the main features and
controls of the S16T htpc enclosure.
10
2
7
3
12 13
14
19 20 21 22 23
25
3
