Orion 10DT User Manual

Quick Set-up Sheet for MODEL
:
10DT
1
To use DC POWER
1. Connect the supplied car cord to the DC 12 V input jack.
2. Start the car engine and insert the other end of the DC Power cord into a cigarette lighter socket of your car.
Then the STAND BY( ) indicator will light up.
To use a Household Power Supply
Power supply system
Aerial Connections Connect as follows.
Note:
Main power (ON/OFF) switch is on the rear panel and it is OFF when not in use for a long time.
OUTPUT
•
SORTIE
RF IN
ON OFF
MAIN POWER
SCART
PRISE PERITEL
COAXIAL
DIGITAL
AUDIO
ANALOGUE
AUDIO
L(G)
R(D)
Mains Lead
Aerial
Indoor Aerial
Main power
(ON/OFF) switch
Use the AC line cord provided for operation on AC. Insert the AC cord plug into 240 V 50 Hz AC outlet.
Press MAIN POWER switch on the back panel, the red standby indicator will light. Turn on your unit by pressing
Sub Power (
) on the front panel or on the remote control, the red standby indicator goes off.
WARNING: Never watch the unit while driving the vehicle.
OUTPUT
•
SORTIE
RF IN
ON OFF
MAIN POWER
SCART
PRISE PERITEL
COAXIAL
DIGITAL
AUDIO
ANALOGUE
AUDIO
L(G)
R(D)
To Cigarette
Lighter Socket
CAR
To DC Input Jack
Car Cord
