Orion 9829 User Manual

Figure 1. The SkyView Pro EQ Mount.
2
Declination lock lever
(opposite side)
Right ascension lock lever
(opposite side)
Declination slow-motion
control knob
Safety thumbscrew
Mounting plate securing knob
Counterweight shaft
Counterweights
Counterweight lock knobs
Tripod leg
Leg lock knobs
Right ascension slow-motion
control knob
Latitude scale
Latitude adjustment L-bolts
Center support shaft
Tripod support tray
Tube ring mounting plate

Orion 9829 Specifications

General

Brand	Orion
Model	9829
Category	Racks & Stands
Language	English
