13
Meet the Finder Scope
(EZ Finder II, Red Dot Finder)
A finder scope helps you point the telescope with accuracy. The EZ Finder II works by projecting a
tiny red dot onto a screen mounted in the front of the unit, so that when you look through the screen,
the red dot will appear to float in space. When the EZ Finder is properly aligned with the telescope,
brightness
knob
Vertical
adjustment knob
Horizontal
adjustment knob
Focusing knobs
Eyepiece
focal length
indicator
Twist
eyepiece to
adjust focal
length (zoom)

Other manuals for Orion StarBlast 4.5

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Orion StarBlast 4.5 and is the answer not in the manual?

Orion StarBlast 4.5 Specifications

General IconGeneral
Aperture114mm
Focal Length450mm
Focal Ratiof/4
Optical DesignNewtonian Reflector
Mount TypeAltazimuth
Finder ScopeEZ Finder II
Weight13 lbs
Eyepieces Included25mm and 10mm
Magnification Range18x
