Telescope Parts
1) Eyepiece (Zoom 8 to 24 mm)
2) EZ Finder with AA battery box
(See picture below)
3) Telescope tube
4) Focuser (See picture below)
5) Tube Clamp
6) Altitude Clamp
7) Mirror Assembly
8) Support
9) Handle
10) Eyepiece rack (removed)
11) Eyepieces
12) Mount Feet
13) Secondary Mirror Screws
14) Secondary Mirror
3
DO NOT TRY TO ADJUST THE ITEMS IN RED
