ORKEL MP 2000 - 5.2.4.1 Lubrication scheme

76

 Use only grease of with extra protecon () addives.
 Shell GADUS S3 V220C 2, Statoil Greaseway CAH 92 or similar
 Approximately number of strokes, grease gun. (unl grease become visible)



 


 
1,2,3,4 Feeder table 50 Driving roller 4
5,6 Feeder table 50 Support roller 4
7,8 Base plate 250 2
9,10,11,12 Feeder table cylinder 50 2
13,14 Elevator 50 Support roller 6
15,16 Elevator 50 Driving roller 6
17,18,19,20,21,22 Belt tensioner, chamber 50 Rear belt 2
23,24,25,26,27,28,29,30 Belt tensioner, chamber 50 Front belt 2
31,32,33,34 Chamber cylinder 50 2
35,36 Belt under 50 Bearing point 6
37,38 Driving roller, belt under 50 Bearing point 6
39,40,41,42
Driving roller, wrapper
table
50 Bearing point 4
43,44
Front roller, wrapper ta-
ble
50 Behind belt edge 2
45,46,47,48,49,50,51,52,5
3,54,56,57
Knife arm 50
Two pcs under
bracket
3
58,59,60,61 Cylinder, wrapper table 50 2
62,63 Emergency stop, wrapper 250 Safeguard bow 2
64,65 Drag x
Check before
transport
6
66 Drag loop X
Check before
transport
2
67 Hand brake X
Check before
transport
2
68,69,70,71,72,73 Brake sha, support’s x
Check before
transport
2
