IM0973270 A 09
Safety
In order to guarantee safe operation, these safety
instructions must be read before you start using
this equipment.
• Do not open the enclosure. This can cause
damage, short-circuiting or electrical shocks.
• Do not expose the equipment to extreme
temperatures. This can cause deformation of the
enclosure or damage to internal components.
• Repairs may only be made by the manufacturer.
• The equipment must be installed as shown in
this manual.
Before you start using this equipment, please read this manual
carefully and follow all instructions. This installation manual
describes the installation of the equipment, outlines the
connection options and explains how to put the equipment into
operation. We recommend that you keep this manual in a safe
place for reference purposes.
If you have any questions or issues concerning the operation
of this equipment, consult the relevant section in the manual or
contact the Orlaco Products BV Service department.
All data subject to change without notice. All dimensions are for
commercial purpose only. The camera/display systems from
Orlaco comply with the latest CE, ADR, EMC and mirror-directive
regulations, where applicable. All products are manufactured in
accordance with the ISO 9001 quality management system, IATF
16949 quality automotive, ISO 14001 environmental management
systems, where applicable.
Contents page
1. Monitor placement 3
2. Basic system installations 4
2.1. EMC 5
3. RLED variants 6
4. Technical specifications 8
5. Back plate 9
6. Assembly, connections and data RLED 10
7. Maintenance and cleaning 33
8. Disposal 33
9. General terms and conditions 33
10. Version details 34
11. Copyright 35
Monitor 7'' RLED
Installation manual
Do not apply voltage to
the output power of the
monitor!
