Ormazabal cgm.3-p User Manual

IG-183-EN version 06; 31/03/2020
83
General instructions
cgm.3 system: medium voltage SF
6
gas-insulated
cubicles up to 38 kV according to IEEE and CSA standards
Maintenance
9. Retighten the O-ring with the cover.
Figure 7.12. Position of the two bolts
10. Bring back the connection cable to the front part of
the gas tank and insert it into the driving mechanism
compartment.
Figure 7.13. Bringing back the connection cable to the front part
