IG-183-EN version 06; 31/03/2020
84
Maintenance
General instructions
cgm.3 system: medium voltage SF
6
gas-insulated
cubicles up to 38 kV according to IEEE and CSA standards
11. Insert the end of the cable through the bulkhead of the
driving mechanism compartment.
Figure 7.14. Inserting the end of the cable
12. Connect the connection cable to the concentrator.
Figure 7.15. Cable connection
13. Fit the driving mechanism cover.
