IG-183-EN version 06; 31/03/2020
19
General instructions
cgm.3 system: medium voltage SF
6
gas-insulated
cubicles up to 38 kV according to IEEE and CSA standards
Transport
2.2. Location of documentation and accessories during transport
During transport, the cubicle must be perfectly seated and
xed so that it cannot move about and possibly damage the
equipment.
The corresponding documentation (General Instructions,
electrical diagrams, etc.) is supplied with the cubicles, as
well as a set of accessories located at the rear of the cubicles,
as indicated in the gures below:
The cubicle models with internal arc for 1 s have the
accessories box located on the roof of the tank.
2.2.1. p modules
Figure 2.5. Location of documentation and accessories
