Ormazabal cgmcosmos-l User Manual

1.3. Main components
1
Gas tank
1.1
Side connection female bushings
2
Driving mechanism area
2.1
Actuating shafts (see mimic diagram of each model)
2.2
LRM-VDS system according to NBN EN 61243-5
3
Base
3.1
Cable compartment access cover
3.2
Medium voltage cable xing support
3.3
Gas relief compartment
3.4
Earth collector
3.5
Front cable connection bushings
* Optional elements.
Figure 1.1. Main components of the cgmcosmos cubicles
IG-296-EN version 01; 12/03/2020
5
General instructions
cgmcosmos: Medium voltage cubicles with full insulation
in SF
6
gas up to 24 kV in accordance with IEC Standard
General description
