13
Pin Function Pin Function
1 +3 V 23 Reserved
2
3 V
24 Reserved
3 Spare Bus 25 Reserved
4 Reserved Bus 26 Spare
5 Coaxial 27 Spare
6 Coaxial *28 +24 V
7 Coaxial *29
24 V
8 200 V dc 30 Spare Bus
9 Spare 31 Spare
*10 +6 V 32 Spare
*11
6 V
*33 117 V ac (Hot)
12 Reserved Bus *34 Power Return Ground
13 Spare 35 Reset (Scaler)
14 Spare 36 Gate
15 Reserved 37 Reset (Auxiliary)
*16 +12 V 38 Coaxial
*17
12 V
39 Coaxial
18 Spare Bus 40 Coaxial
19 Reserved Bus *41 117 V ac (Neutral)
20 Spare *42 High-Quality Ground
21 Spare G Ground Guide Pin
22 Reserved
Pins marked (*) are installed and wired in ORTEC’s Model 4001A and
4001C Modular System Bins.
Table 1. Bin/Module Connector Pin Assignments for Standard
Nuclear Instrument Modules per DOE/ER-0457T
