Hydraulic two staged gear wheel pump, driven by an electrical motor.
The hydraulic functions consists of an electrical directional valve, pressure
switches and two hydraulic cylinders to move the press plate up and
down.
Relief valve to prevent over pressure in the hydraulic system.
Filter on suction side of hydraulic pump.
Check valve on outgoing ow line from hydraulic pump.
ELECTRICAL SYSTEM
Electrical voltage standard 3 x 400-415V plus earth with neutral phase, 10A
for Europe. Other markets according to country standards.
Control voltage 240V AC.
Electrical circuit is protected with a circuit breaker.
Control circuit is protected with a glass fuse mounted on the PCB.
The control buttons are of mechanical type.
Connection cable ve wire 2.5 mm
2
with ve pole CEE - plug for European
market.
