OSHIMA K5 - Page 58

K5-190 零件表 Parts List 3D-1
NO.
零件号
名称
Compellation
NO.
零件号
名称
Compellation
1
KS3A002
切刀線固定板
Support of Cut Cord
24
KS3B010
刀行導輪軸
Shaft
2
KS3B007
M5 螺帽柱
M5 Nut Pole
25
KS1JB2067
626ZZ 包膠ψ22
Rubber Bearing
3
K5A044
切刀 A 側 L 板
L-plate A
26
KS3B012
圓刀片銅蓋
Fixer of Blade
4
KS3A003
刀行量近接座
Stand of Sensor
27
05.04.09.1401
圓刀片
Blade
5
04.04.14.1201
刀行量近接開關
DS-M105-18a
Close Sensor
28
K1A004
刀行近接感應器
Cut-Moving Senseware
6
KS3B004
套筒
Sleeve
29
04.08.03.2201
滑車蓋
Cover of Trolley
7
KS3B264
刀行時規皮帶惰輪
Timing Pulley
30
04.08.03.2302
板塊集電子
Elec. Collector
8
04.03.01.1041
切刀 A 側蓋
Cover
31
KS3B008
滑车塑胶（上）
Trolley Upper Plastic
9
04.04.17.1201
24pin 公接頭 MC24WSM2
24pin Plug
32
KS3A008
刀行皮帶上固定片
Fixer of XL-open
10
04.04.18.2121
刀行馬達 M-4IK25N-S
Blade-moving Motor
33
04.07.03.1273
刀行皮帶
XL-open Timing Belt
11
04.04.19.1402
齒輪箱 G-4N3-K
Gear Box
34
KS3A009
刀行皮帶下固定片
Fixer of XL-open
12
KS3A006
切刀 B 側 L 板
L-plate B
35
KS3B306
刀行皮帶培林軸
Bearing Axis of Knife Belt
13
KS3A005
切刀電軌
Cutter's Duct
36
KS1JB2066
625ZZ 包膠
Rubber Bearing
14
04.05.01.0111
壓布馬達啟動電容 1μ
Capacitor
37
KS3B307
行走輪螺桿
Screw of Wheel
15
04.03.01.1042
切刀 B 側蓋
Cover
38
KS3B009
滑車塑膠（下）
Trolley Lower Plastic
16
KS3B265
刀行皮帶輪
Timing Pulley
39
KS3A011
圓刀馬達板
Stand of Blade Motor
17
KS3B292
PU 膠管
PU Rubber
40
KS3A010
圓刀馬達墊片
Plate of Blade Motor
18
KS3B344
磨石螺母
Nut of Stone
41
KS3B280
圓刀片套蓋
Base of Blade Motor
19
KS3B345
磨石壓簧
Spring
42
04.04.18.1101
圓刀馬達
Blade Motor
20
KS3A117
磨石座
Stand of Grinder
43
KS3A013
底刀板
Lower Blade Plate
21
06.09.02.1001
磨石(含牙座)
Grinding Stone
44
05.04.09.1301
底刀片
Lower Blade
22
KS3A016
圓刀馬達蓋
Cover of Blade Motor
45
KS3B199
底刀座
Stand of Lower Blade
23
KS3A017
退刀護片
Protector of Blade
46
04.07.01.2101
培林 6000ZZ
Bearing
57
