OSHIMA K5 - Page 59

K5-190 零件表 Parts List 3D-2
NO.
零件号
名称
Compellation
NO.
零件号
名称
Compellation
1
K5A045
壓定位感應器
Press Sensor
16
KS3B026
壓布軸 B 側鋁塊
Al-Block
2
KS3A026
刀行 A 近接座
Stand-A of Closer
17
K5A085
切刀壁 B
Frame-B of Cut
3
04.04.14.1201
近接开关 QL-05N 常开
Close Sensor
18
KS3A025
刀行 B 近接座
Stand-B of Closer
4
KS3B021-L
突桿座 A
Aid Plate Stand-A of Finger
19
KS3B021-R
突桿座 B
Aid Plate Stand-B of Finger
5
K5A084
切刀壁 A
Frame-A of Cut
20
KS3A104
掃風桿-190
Wind Sweeper
6
KS3A019
電軌 M5 螺帽片
M5 Nut Plate
21
K5A047
壓布馬達鐵塊
Iron-Block of Press Motor
7
KS3B016
突桿軸
Shaft
22
K5A046
押布 LS 固定板
Stand of Limit SW
8
KS3B017
突桿
Finger
23
K5B054
壓布馬達柱
Press Motor Pole
9
KS3A020
滑板固定耳
Stand of Slide
24
K5B055
壓布馬達柱
Press Motor Pole
10
K5A001
滑板-190
Cutter Slide
25
04.04.19.1103
齒輪箱 G-2N150-L
Gear Box
11
KS3B018
連結扁管-190
Joint Rectangle Pipe
26
04.04.18.2101
壓布馬達 M-2RK6N-C
Press Motor
12
KS3A022
壓布彈簧片
Leaf Spring
27
04.04.13.0202
微动开关 V-155-1A5
Micro Switch
13
KS3A102
壓布鋁扁條-190
Cutter's Press Bar
28
04.07.01.3021
乾式軸承 DU1206
Bearing
14
K5B085
壓布軸-190
Shaft
29
04.07.01.2052
培林 625ZZ
Bearing
15
KS3B312
壓布軸拉簧
Spring
58
